Features:

The 3D mold digital hot stamping technology is a new technology with independent intellectual property rights, which is a non-bronzing plate

of the hot stamping technology. lt absorbs the advantages of traditional cold stamping and hot stamping not only it can realize a large area

fine texture bronzing that hot stamping can not complete, but also it can complete raised relief visual sense and touch stereoscopic experience

that the cold stamping can not complicated. In addition,it makes the hot stamping process become more simple and efficient.

No bronzing plate, it saves the time to make a sample.

No bronzing plate, it saves the time to change the plate.

Nobronzing plate,it eliminates the time of adjusting the pressure.





Specification



Sheet Size(WxL)	Max. 600x900mm
	Min. 210x297mm
Gram Weight	157 -600g/m2
Thickness	0.13 - 0.8 mm
Paper type	Carton board, coated paper, film paper
Pile Height	900 mm
Pile Weight	Max. 1,000 kg
Volume (LxHxW)	7x 1.9x 1.8 m
Net Weight	About 8,000kg
Print Max Speed	35m/min or 2200 S/h
Print Max Width	540 mm

Foiling Specification

Rewinder and Unwinder	Independent Servo Control	Multi-channel foil strip
Foil Diameter	Max.	400	mm
Core Diameter		76.2	mm
Foil Width		50–600	mm
Foil Gap	Min.	30	mm
Speed (MAX )	35m/min	2200	Sheet/h
Foil shaft quantity	1 set
Heating methods: electric heating, internal heating and external heating, roller surface temperature uniformity



Application
